Introduction of mobile concrete mixing plant equipment

Our mobile concrete batching plants are specially designed for the production of high-quality concrete. A mobile concrete batch plant is a portable, efficient, reliable and cost-effective piece of equipment for producing concrete batches in virtually any location. Our large capacity mobile concrete batching plants are suitable for large construction, infrastructure and civil engineering projects. Our mobile concrete batching plants are designed for projects that require changing job locations from time to time. It is easy to disassemble and move to another job site, and it is also easy to install. Almost all construction projects use concrete, and concrete factories now produce concrete using precise weighing and high-mixing techniques. Aggregate, cement, water and additives are accurately weighed on weighing scales according to the concrete formula determined by previous laboratory tests, and uniformly mixed by high-efficiency and fast concrete mixers to produce high-quality concrete.
In the past, all concrete mixing plants were produced by stationary concrete mixing plants. Even the smallest concrete mixing plants can be installed within a certain period of time after being transported by four to five trucks; these fixed mixing plants have been in use for many years Concrete is produced in the same place. The increase in the number of construction projects and the amount of concrete required for these projects, as well as the need to complete these projects within a short period of time, has led construction companies to produce the concrete required for their projects.

Over time, construction companies have required mobile concrete plants that are more flexible, easier to transport and easier to install than stationary concrete plants as they need to move the plant from one location to another when completing projects. Mobile concrete plants are designed to meet these needs. Mobile concrete batching plants consist of the same units as stationary concrete batching plants, where the units are fixed to a chassis with axles and wheels. When this chassis is towed by a truck tractor, the mobile concrete batching plant can be easily transported.
What are the advantages of mobile concrete mixing plants?

1- Easier to transport. The main body of the mobile concrete plant can be transported by truck tractor.

2- Faster and easier installation, removal and transfer. flexibility.

3- Small installation space. Can be installed in the project area.

4- Less concrete foundation requirements. Can be installed on a flat concrete floor.

5- Easier installation permission. In some cases, no permission is required.
Where to Use Mobile Concrete Batching Plant

Mobile concrete batching plants are the product of complex engineering. By aesthetic design, all units are placed in a small area. Ready-mix concrete companies also prefer major construction projects where they supply concrete, by setting up mobile concrete plants within the project area to produce concrete only for that project.

Features of mobile concrete plant

Aggregate hoppers for storing aggregates, aggregate weighing conveyors for weighing aggregates, cement weighing scales, water weighing scales, chemical weighing scales and concrete mixers for uniform and fast mixing of all these materials is placed on the host. The axles and wheels are placed on the back of the main unit. The truck tractor can be installed on the main pin at the front of the main engine to transport the main engine.
Units Required for Mobile Concrete Mixing Plants

The other units required for the mobile concrete plant, namely the cement silo, cement conveyor, cement silo filter and aggregate pre-feeding system, can be transported in standard trucks or containers. In mobile concrete plants, the aggregate hopper is generally a square hopper with two aggregate chambers on one side and two aggregate chambers on the other. The aggregate hopper can be filled via a concrete/steel aggregate loading ramp, or more efficiently via an aggregate pre-feeding system. There are two types of aggregate prefeeding systems.

1- Compact aggregate pre-feeding system (can be transported by truck or container)

2- Mobile aggregate pre-feeding system (just like Mobil main engine, axles and wheels are placed in the back, can be transported by truck tractor)

Installation time of mobile concrete mixing plant

Cables and water and pneumatic system piping on mobile concrete batching plants are usually installed during factory production at the plant. This saves a lot of time at the installation site and shortens the installation time of mobile equipment. A medium capacity stationary concrete batching plant can be installed in 14-21 days, while a mobile concrete batching plant can be installed in 7-9 days.

What is the difference between a mobile concrete batching plant and a stationary concrete batching plant?

Fixed features and advantages: 1. Compact structure and reliable performance. 2. Computer control, easy to operate. 3. Compulsory mixer, high working efficiency. 4. Operation in a closed space, the equipment is environmentally friendly. 5. Belt type and hopper are optional.

Features and advantages of the mobile mixing plant: 1. Special structure, easy to disassemble and assemble. 2. Belt drive system, high conveying efficiency. 3. Compulsory mixer, high work efficiency. 4. Computer control, easy to operate. 5. Compact structure and reliable performance.

A mobile concrete batch plant batches your concrete where you want to use it. Dosing directly into concrete pumps, dump trucks or ready-mix trucks. No waste, only batch what you need. No more waiting for a premix truck, it will be there when you need it. After the job is done, move your factory to the next one.
Mobile concrete batching plants offer an economical and flexible solution for small to medium investments. It can be used in multiple projects without installation cost. A mobile concrete mixing plant can do everything any stationary concrete plant can do. All the equipment that makes up the plant is concentrated on one chassis. The mobile concrete batching plant is specially designed for the projects where we need to change the working place from time to time. It is easy to disassemble and move to another job site, and it is also easy to install. All parts are movable and do not require a reinforced concrete foundation, including the cement silo. So it’s easy to install on a new job site; you just need a vehicle to tow it to the new job site, put the machine in the right place and connect the cables, and you’re good to go. Usually, we can complete the installation within 3 days;

Mobile mixing plants are ideal for temporary construction sites or construction projects where the equipment is only used for specific and brief parts of the project. The mobile concrete mixing plant can be easily installed and disassembled. We have a wide range of products from 20 ³/h to 120 m³/h. High-quality concrete can be produced for a variety of projects where concrete is used in a ready-mix concrete mixing plant. Mobile concrete batching plant is the most popular model of concrete batching plant produced by our company. Mobile concrete batching plants offer an economical and flexible solution for small to medium investments. Our mobile concrete batch plants are suitable for temporary installations, special projects or permanent installations.
